[MapProxy] MapProxy WMTS question

[Randy Milbert]

Hi,

I am trying to configure MapProxy to enable me to access a WMTS service via WMS or TMS.  Here is the source service:

http://tiles.arcgis.com/tiles/ovln19YRWV44nBqV/arcgis/rest/services/ScottIA_2014Aerial/MapServer
http://tiles.arcgis.com/tiles/ovln19YRWV44nBqV/arcgis/rest/services/ScottIA_2014Aerial/MapServer/WMTS/1.0.0/WMTSCapabilities.xml
http://tiles.arcgis.com/tiles/ovln19YRWV44nBqV/arcgis/rest/services/ScottIA_2014Aerial/MapServer?f=jsapi

Here is my MapProxy instance:

http://104.197.62.82:8080/demo/

Here is my MapProxy configuration file:

services:
   demo:
   tms:
   wms:
layers:
- name: scott_layer
   title: Scott
   sources: [scott_cache]
caches:
   scott_cache:
      grids: [scott_grid]
      sources: [scott_source]
sources:
   scott_source:
      type: tile
      grid: scott_grid
      url: http://tiles.arcgis.com/tiles/ovln19YRWV44nBqV/arcgis/rest/services/ScottIA_2014Aerial/MapServer/tile/%(z)s/%(y)s/%(x)s
grids:
   scott_grid:
      origin: 'nw'
      bbox: [2341500.5208333135, 533999.4791666567, 2517000.5208333135, 662999.4791666567]
      srs: 'EPSG:3426'
      res: [
         #  res            level     scale @90.7 DPI
          868.0555554189, #  0     3100198.41221019
          434.0277777094, #  1     1550099.20610510
          217.0138888547, #  2      775049.60305255
          108.5069444274, #  3      387524.80152627
           55.5555555468, #  4      198412.69838145
           27.7777777734, #  5       99206.34919073
           13.8888888867, #  6       49603.17459536
            6.9444444434, #  7       24801.58729768
            4.1666666660, #  8       14880.95237861
            2.0833333330, #  9        7440.47618930
            1.0416666665, # 10        3720.23809465
            0.5208333333, # 11        1860.11904733
      ]

Here is a working tile from the source service:

https://tiles2.arcgis.com/tiles/ovln19YRWV44nBqV/arcgis/rest/services/ScottIA_2014Aerial/MapServer/tile/2/1301/1095?cacheKey=966cb1e11315bed4

Here is a broken image from MapProxy:

http://104.197.62.82:8080/service?LAYERS=scott_layer&FORMAT=image%2Fpng&SRS=EPSG%3A4326&EXCEPTIONS=application%2Fvnd.ogc.se_inimage&TRANSPARENT=TRUE&SERVICE=WMS&VERSION=1.1.1&REQUEST=GetMap&STYLES=&BBOX=-90.596385,41.506737,-90.541931,41.530870&WIDTH=840&HEIGHT=600

Do you know what I am doing wrong?

Thanks for your help!

Randy
